Item: YB-LG-20M - LG-20M LED Power Driver ( LED Power Supply )

Item: YB-LG-20M
Product Name: LG-20M LED Power Driver ( LED Power Supply )

  • Constant current mode
  • Isolated power supply with plastic case
  • Build in protection function of short circuit, over current, over voltage and over temperature
  • With 1-10v dimming function
picture (image) of lg-20m.jpg

Description

Power: 20W
Application: Flood light, Stage light and Area light
Certificates: UL ClassP, TUV, CCC, CE
5 Years Warranty

Features

Efficiency up to 86%
Dimming(Optional): 0-10V, PWM, Resistor
IP65
Protections: SCP/OCP/OVP/OTP
Surge Protection: L-N: 2kV
Operation temperature: -40~+60



Model AC Input Range DC Output Range Output Current Output Power
LG-20M023 (100-277)Vac (11-23)Vdc (0.6-1)A 20W
LG-20M042 (100-277)Vac (24-42)Vdc (0.35-0.6)A 20W
LG-20M054 (100-277)Vac (33-54)Vdc (0.25-0.4)A 20W






FAQs:

1. How long does it take to get the quotation?
For any interest of our products, you are very welcome to send us feedback or contact us. We will reply ASAP! Generally it takes within 12 hours. For any quick response, please call us directly.

2. How can I get a sample?
Samples are free, however, we charge the shipping cost, which could be deducted in the later order as long as the amount reach our MOQ.

3. Can you provide OEM or ODM service?
Surely we can. We have a professional team which has rich experience in lighting field. A lot of our products carrying our ideas are well sold in North America and European market.

4. What's the lead time for mass production?
It depends on the amount. Generally it takes a month after deposit payment for us to finish the order.

5. What is the terms of delivery?
Generally we offer FOB, however, EXW,CIF,etc are also welcome. Feel free to choose the one suit you best.
